Product Introduction

This electric double-girder overhead crane consists of a bridge, trolley mechanism, trolley, and electrical equipment. The crane can be operated from the cab, either from the ground or from the ground.

Parameters

1. Lifting capacity: 5-32/5t (customizable upon request)

2. Span: 10m-35m (customizable upon request)

3. Lifting height: customizable upon request

4. Trolley speed: 40-90m/min (optional), trolley speed: 40m/min

5. Main hook lifting speed: 12.5m/min

6. Track width: 38, 43, or 50kg/m (depending on tonnage and span)

7. Working class: A5-A8

8. Operating temperature: -25°C to 40°C

Applications

Mostly used in machinery manufacturing, assembly workshops, warehouses, and other locations. If equipped with a motorized grab bucket as a lifting device, it can be used for loading, unloading, and transporting bulk materials. However, it is not suitable for use in environments with explosive or fire hazards, high humidity, or areas filled with acidic or alkaline gases. It is also not suitable for transporting molten metals, toxic substances, or flammable or explosive materials.

Structural Advantages

Services

1. Pre-sales Service

Understand customer needs and help customers select the right products.

Provide technical support before equipment installation.

Provide in-factory training for equipment operation, repair, and maintenance personnel.

2. Post-sales Service

According to contract requirements, track, produce, and ship equipment to ensure it arrives safely and intact at the customer's designated location.

Provide all necessary technical specifications for pre-installation.

3. After-sales Service

Install, commission, and repair equipment according to the contract or customer's agreed-upon schedule.

Provide on-site training based on customer needs.

Handle customer complaints regarding product and service quality and promptly arrive on-site to resolve issues.

Establish equipment user profiles, archive and maintain complete installation, commissioning, and maintenance records for each device. Ensure traceability of service for each customer and each product, and provide technical support for the maintenance of each device.

Conduct regular customer follow-up visits to collect customer feedback and suggestions on products and services and promptly address them.

Each service station is centrally coordinated by the after-sales service station to ensure the timeliness and effectiveness of the service.
